Transparent Acrylic Pump Head machined
Model ：
CNC Machining
Introduction
Categotry
CNC machining
Kerword
Share:
VIDEO
DESCRIPTION
Name: Transparent pump head
Material: Acrylic
Features: Ductile material, after complex structural processing, still full permeability.
CNC-machined acrylic pump heads offer superior precision, chemical resistance, and transparency compared to metal or plastic alternatives. They are ideal for applications requiring leak-proof performance and visual flow verification.
Key Features of CNC Machined Acrylic Pump Heads
1. Material Advantages
-
Optical Clarity: Allows real-time visual inspection of fluid flow.
-
Chemical Resistance: Resists acids, alkalis, and solvents (compatible with water, weak acids, and alcohols).
-
Lightweight & Durable: Lower density than metals, yet impact-resistant.
2. Precision Machining Capabilities
-
Tight Tolerances (±0.05mm): Ensures leak-proof sealing with O-rings and gaskets.
-
Complex Internal Channels: CNC milling/lathing enables intricate flow paths.
-
Smooth Surface Finish (Ra <0.8µm): Reduces friction and turbulence in fluid transfer.
3. Common Applications
-
Laboratory & Medical: Peristaltic pumps, chromatography systems.
-
Food & Beverage: Hygienic liquid transfer (FDA-compliant).
-
Chemical Processing: Corrosion-resistant dosing pumps.
-
Aquariums & Water Treatment: Clear housing for monitoring fluid levels.
CNC Machining Process for Acrylic Pump Heads
1. Material Selection
-
Cast Acrylic (PMMA): Preferred for machining due to low internal stress.
-
Extruded Acrylic: Less expensive but prone to cracking during machining.
2. Machining Techniques
-
Milling: Creates ports, grooves, and mounting features.
-
Turning: Produces cylindrical shapes (e.g., threaded fittings).
-
Drilling & Tapping: For hose connectors and assembly screws.
-
Laser Cutting (Optional): For ultra-fine details.
